National Item Identification Number
00-422-7646
004227646
4730-00-422-7646
4730004227646
National Stock Number
Item Name
TEE,FLANGE TO PIPE
Federal Supply Class
4730
Referenced on: http://constructioncranes.tpub.com//TM-5-3810-294-34P/css/TM-5-3810-294-34P_611.htm
Referenced on: http://constructioncranes.tpub.com//TM-5-3810-294-34P/css/TM-5-3810-294-34P_709.htm
Referenced on: http://constructioncranes.tpub.com//TM-5-3810-294-34P/css/TM-5-3810-294-34P_845.htmDescription
A fitting having three connections with the branch connection fixed at 90 degrees (1.5705 radians) to the run. The flange connection(s) is designed to connect with another flange connection or a compression type mounting pad. The pipe connection(s) has standard pipe threads or is unthreaded and designed to accommodate a pipe. It may have side inlet(s). It is used as a junction at the intersection of a flange or flange fitting and a pipe or pipe fitting.
Commercial and Government Entity Code (Supplier Data)
06853
ALLIEDSIGNAL TRUCK BRAKE SYSTEMS
BENDIX-GARRETT
901 CLEVELAND ST
ELYRIA
OH
44036
440-329-9000
06853
ALLIEDSIGNAL TRUCK BRAKE SYSTEMS
BENDIX-GARRETT
901 CLEVELAND ST
ELYRIA
OH
44036
440-329-9000
NSN (National Stock Number) 4730-00-422-7646, 4730004227646 NIIN (National Identification Number) 00-422-7646, 004227646
Part Numbers (Reference Numbers)
T-212208B
217697
Required Categories
MATERIAL
CONNECTION TYPE
CONNECTION STYLE
FLANGE SHAPE
NOMINAL THICKNESS
NO
Required Description
ALUMINUM OVERALL
THREADED INTERNAL PIPE 1ST END
FLANGE 2ND END
FLANGE 3RD END
