National Item Identification Number
00-421-1467
004211467
4730-00-421-1467
4730004211467
National Stock Number
Item Name
TEE,PIPE TO TUBE
Federal Supply Class
4730
Description
A fitting having three connections with the branch connection fixed at 90 degrees (1.5705 radians) to the run. The pipe connection(s) has standard pipe threads, or is unthreaded and designed to accommodate a pipe. The tube connection(s) has machine threads (straight threads other than pipe or hose series) designed to accommodate a tube, or is unthreaded and designed to accommodate a tube. It may have side inlet(s). It is used as a junction at the intersection of pipe or pipe fitting and a tube or tube fitting.
Commercial and Government Entity Code (Supplier Data)
24617
NSN (National Stock Number) 4730-00-421-1467, 4730004211467 NIIN (National Identification Number) 00-421-1467, 004211467
Part Numbers (Reference Numbers)
118758
1188758
Required Categories
MATERIAL
CONNECTION TYPE
CONNECTION STYLE
SEAT ANGLE
NOMINAL OUTSIDE DIAMETE
Required Description
COPPER ALLOY OVERALL
THREADED EXTERNAL TUBE 1ST END
THREADED EXTERNAL TUBE 2ND
