National Item Identification Number

00-504-3411
005043411
4730-00-504-3411
4730005043411

National Stock Number

Item Name

FLANGE,PIPE

Federal Supply Class

4730

Referenced on: http://constructioncranes.tpub.com//TM-5-3810-232-34P/css/TM-5-3810-232-34P_1030.htm
Referenced on: http://constructioncranes.tpub.com//TM-5-3810-232-34P/css/TM-5-3810-232-34P_1127.htm
Referenced on: http://constructioncranes.tpub.com//TM-5-3810-232-34P/css/TM-5-3810-232-34P_1328.htm

Description

An item solid or split into halves, having a threaded or unthreaded hole for the purpose of connecting or retaining a pipe, tube, or hose fitting. The face of the flange may be smooth, grooved, or serrated and may be drilled for connecting bolts or studs. If the item is unthreaded, the pipe or tube may be retained by welding, brazing, compression, or the like. Excludes FLANGE, PIPE, BLIND; FERRULE, GROOVED CLAMP COUPLING; and ADAPTER (as modified).

Commercial and Government Entity Code (Supplier Data)

---

15434

---

CUMMINS INC
500 JACKSON ST
COLUMBUS
IN
47201
812-377-7437

---

15434

---

CUMMINS INC
500 JACKSON ST
COLUMBUS
IN
47201
812-377-7437

---

NSN (National Stock Number) 4730-00-504-3411, 4730005043411 NIIN (National Identification Number) 00-504-3411, 005043411

Part Numbers (Reference Numbers)

BM25445
103535

Required Categories

MATERIAL
STYLE DESIGNATOR
BOLT CIRCLE DIAMETER
FLANGE LENGTH
BOLT HOLE DIAME

Required Description

STEEL
3 OVAL, ONE BOLT HOLE CIRCLE
2.500 INCHES NOMINAL
3.391 INCHES NOMINAL;
