National Item Identification Number

01-190-0390
011900390
4730-01-190-0390
4730011900390

National Stock Number

Item Name

ELBOW,FLANGE TO HOSE

Federal Supply Class

4730

Referenced on: http://constructioncranes.tpub.com//TM-5-3810-306-24P/css/TM-5-3810-306-24P_540.htm
Referenced on: http://constructioncranes.tpub.com//TM-5-3810-306-24P/css/TM-5-3810-306-24P_572.htm
Referenced on: http://constructioncranes.tpub.com//TM-5-3810-306-24P/css/TM-5-3810-306-24P_757.htm
Referenced on: http://constructioncranes.tpub.com//TM-5-3810-306-24P/css/TM-5-3810-306-24P_761.htm

Description

A fitting that forms an angle of less than 180 degrees (3.141 radians) from the straight flow. It has a flange connection on one end designed to connect with another flange connection, or a compression type mounting pad. The other end has standard hose threads, an incomplete part of a threaded end connection that grips the hose directly, or is unthreaded and designed toaccommodate a hose. It may have side and/or heel inlet(s).

Commercial and Government Entity Code (Supplier Data)

---

01276

---

---

01276

---

---

NSN (National Stock Number) 4730-01-190-0390, 4730011900390 NIIN (National Identification Number) 01-190-0390, 011900390

Part Numbers (Reference Numbers)

FC9152-2020S
1S20FLB20

Required Categories

MATERIAL
SURFACE TREATMENT
CONNECTION TYPE
CONNECTION STYLE
FLANGE SHAPE
NO

Required Description

STEEL OVERALL
CADMIUM OVERALL
FLANGE 1ST END
UNTHREADED INTERNAL HOSE 2ND END
