National Item Identification Number
01-198-2852
011982852
4730-01-198-2852
4730011982852
National Stock Number
Item Name
COUPLING HALF,QUICK DISCONNECT
Federal Supply Class
4730
Referenced on: http://constructionmixers.tpub.com//TM-5-3895-359-24P/css/TM-5-3895-359-24P_319.htm
Referenced on: http://constructionmixers.tpub.com//TM-5-3895-359-24P/css/TM-5-3895-359-24P_359.htm
Referenced on: http://constructionmixers.tpub.com//TM-5-3895-359-24P/css/TM-5-3895-359-24P_437.htmDescription
A fluid line fitting having a pipe, tube or hose connection or a through hole to accommodate a BOLT, FLUID PASSAGE on one end. The other end must have an internal or external quick disconnect feature for connecting a mating part to form a quick disconnect coupling assembly. The fitting may incorporate a self-sealing feature for the purpose of automatically shutting off the flow of fluid when disconnected from its mating half. For self-sealing fittings with an external or internal threaded disconnect end, see COUPLING HALF, SELF-SEALING. See also, CONNECTOR, MULTIPLE, FLUID PRESSURE LINE.
Commercial and Government Entity Code (Supplier Data)
24869
DVCC INC
ANDREWS CAM AND GROOVE COUPLERS DIV
800 HIGH ST
CHESTERTOWN
MD
21620
410-778-2000
24869
DVCC INC
ANDREWS CAM AND GROOVE COUPLERS DIV
800 HIGH ST
CHESTERTOWN
MD
21620
410-778-2000
NSN (National Stock Number) 4730-01-198-2852, 4730011982852 NIIN (National Identification Number) 01-198-2852, 011982852
Part Numbers (Reference Numbers)
MH10282
298-311-47
40X30-A
400A
400A-MI
Required Categories
MATERIAL
STYLE DESIGNATOR
LEG LENGTH
OVERALL LENGTH
CONNECTION TYPE
CONNECT
Required Description
STEEL BODY
A1 MALE COUPLING HALF
1.375 INCHES NOMINAL
3.025 INCHES NOMINAL
T
