National Item Identification Number

01-290-9192
012909192
4730-01-290-9192
4730012909192

National Stock Number

Item Name

TEE,PIPE TO TUBE

Federal Supply Class

4730

Referenced on: http://trucktractor6x4.tpub.com//TM-9-2320-273-24P/css/TM-9-2320-273-24P_1081.htm
Referenced on: http://trucktractor6x4.tpub.com//TM-9-2320-273-24P/css/TM-9-2320-273-24P_847.htm
Referenced on: http://trucktractor6x4.tpub.com//TM-9-2320-273-24P/css/TM-9-2320-273-24P_899.htm

Description

A fitting having three connections with the branch connection fixed at 90 degrees (1.5705 radians) to the run. The pipe connection(s) has standard pipe threads, or is unthreaded and designed to accommodate a pipe. The tube connection(s) has machine threads (straight threads other than pipe or hose series) designed to accommodate a tube, or is unthreaded and designed to accommodate a tube. It may have side inlet(s). It is used as a junction at the intersection of pipe or pipe fitting and a tube or tube fitting.

Commercial and Government Entity Code (Supplier Data)

---

34623

---

---

34623

---

---

NSN (National Stock Number) 4730-01-290-9192, 4730012909192 NIIN (National Identification Number) 01-290-9192, 012909192

Part Numbers (Reference Numbers)

MA001-21022
11070

Required Categories

MATERIAL
CONNECTION TYPE
CONNECTION STYLE
THREAD SERIES DESIGNATOR
NOMINAL T

Required Description

STEEL OVERALL
THREADED INTERNAL TUBE 1ST END
THREADED INTERNAL TUBE 2ND END
T
