National Item Identification Number

00-277-1995
002771995
4730-00-277-1995
4730002771995

National Stock Number

Item Name

ELBOW,PIPE TO HOSE

Federal Supply Class

4730

Referenced on: http://www.tpub.com/content/carrierpersonnel/TM-9-2350-247-24P/css/TM-9-2350-247-24P_152.htm
Referenced on: http://www.tpub.com/content/carrierpersonnel/TM-9-2350-247-24P/css/TM-9-2350-247-24P_710.htm

Description

A fitting that forms an angle of less than 180 degrees (3.141 radians) from the straight flow. One connecting end has standard pipe threads or is unthreaded and designed to accommodate a pipe. The other end has standard hose threads, an incomplete part of a threaded end connection that grips the hose directly, or is unthreaded and designed to accommodate a hose. It may have side or heel inlet(s). See also ELBOW, HOSE; ELBOW, PIPE; and CONNECTOR, MULTIPLE, FLUID PRESSURE LINE.

Commercial and Government Entity Code (Supplier Data)

---

NSN (National Stock Number) 4730-00-277-1995, 4730002771995 NIIN (National Identification Number) 00-277-1995, 002771995

Part Numbers (Reference Numbers)

AN842-8D
7429-8
7429X8

Required Categories

MATERIAL
MATERIAL DOCUMENT AND CLASSIFICATION
SURFACE TREATMENT
CONNECTION TY

Required Description

ALUMINUM ALLOY OVERALL
QQ-A-225/4,TEMPER T6 FED SPEC SINGLE MATERIAL RESPONSE O
